/** The grammar for a mechanism description * The format is BNF-like, as used by JavaCC * */ options { STATIC = false; } PARSER_BEGIN(MechanismParser) public class MechanismParser{} PARSER_END(MechanismParser) ////////////////// whitespace and line separators SKIP: { /* white space and comments */ " " | "\n" | "\r" | "\t" | "\f" | "//" : IN_SINGLE_LINE_COMMENT | "/*" : IN_MULTILINE_COMMENT } <IN_SINGLE_LINE_COMMENT> SKIP: { < "\n" | "\r" > : DEFAULT | <~[]> } <IN_MULTILINE_COMMENT> SKIP: { "*/" : DEFAULT | <~[]> } TOKEN: { < REACTION_MARKER: "<->" > } TOKEN: { /* binary operators */ < IF: "?" > | < OR: "|" > | < AND: "&" > | < EQ: "==" > | < LE: "<=" > | < GE: ">=" > | < NE: "!=" > | < LT: "<" > | < GT: ">" > | < ADD: "+" > | < SUB: "-" > | < MUL: "*" > | < DIV: "/" > | < MOD: "%" > | < POW: "^" > } TOKEN: { /* reserved words */ < RATE: "rate(" > // Note: no space before the '(' | < RATECONSTANT: "k(" > | < FINAL: "final" > | < OUTPUT_MARKER: "*output" > | < SCRIPT_MARKER: "*script" > : IN_SCRIPT } <DEFAULT, IN_SCRIPT> TOKEN: { < INT: ["1"-"9"] (["0"-"9"])* > // integers } TOKEN: { /* numbers--from the Java grammar */ < NUMBER: (<DIGIT>)+ ( "." (<DIGIT>)* (<EXPONENT>)? )? | "." (<DIGIT>)+ (<EXPONENT>)? | (<DIGIT>)+ <EXPONENT> > | < #EXPONENT: ["e","E"] (["+","-"])? (["0"-"9"])+ > } <DEFAULT, IN_SCRIPT> TOKEN: { /* identifier--Unicode from the Java grammar; allows ' in names */ < ID: <LETTER> (<LETTER>|<DIGIT>|"'")* > | < #LETTER: ["A"-"Z","a"-"z","$","_"] > | < #DIGIT: ["0"-"9"] > } TOKEN: { // java identifier; starts with @ and allows dots to separate parts of names < JAVAID: "@" <LETTER> (<LETTER>|<DIGIT>|".")* > } // string definition from the Java grammar. <DEFAULT, IN_SCRIPT> TOKEN: { < STRING: "\"" ( (~["\"","\\","\n","\r"]) | "\\" ( ["n","t","b","r","f","\\","'","\""] | ["0"-"7"] ( ["0"-"7"] )? | ["0"-"3"] ["0"-"7"] ["0"-"7"] ) )* "\"" > } ////////////////// Mechanism grammar void mechanism(): {}{ [ reactionBlock() ] [ outputBlock() ] [ scriptBlock() ] <EOF> } void reactionBlock() : {}{ ( [ LOOKAHEAD (reactionLookahead()) reaction() | expression() ] eol() )+ } void outputBlock() : {}{ <OUTPUT_MARKER> ( [ expression() ] eol() )* } void scriptBlock() : {}{ <SCRIPT_MARKER> script () } void eol(): {}{ ";" } ////////////////// Reaction grammar // used for lookahead to decide if a statement is a reaction; don't // need to look for the whole thing, just to the <REACTION_MARKER> void reactionLookahead() : {}{ side() <REACTION_MARKER> } void reaction() : {}{ side() ( <REACTION_MARKER> side() )+ } void side() : {}{ reactant() ( <ADD> reactant() )* } void reactant() : {}{ [ <INT> ] <ID> } ////////////////// Expression grammar void expression(): {}{ assignExpression() | <FINAL> t = <ID> ":" expression() } void assignExpression(): {}{ binaryExpression() [ "=" assignExpression() | ":" assignExpression() ] } // This part of the grammar will determine whether a mechanism is well-formed or not, // but does not parse the precedence of operators correctly. The actual grammar uses // the precedence-climbing algorithm described by // Theodore Norvell void binaryExpression (): {}{ unaryExpression() ( op=binary() binaryExpression () )* } void binary(): {}{ <IF>|<OR>|<AND>|<EQ>|<LE>|<GE>|<NE>|<LT>|<GT>| <ADD>|<SUB>|<MUL>|<DIV>|<MOD>|<POW> } // unary expressions have higher precedence than any binary // consistent, I believe, with Java but not with standard algebraic use // so -x^2 parses as (-x)^2, not -(x^2) void unaryExpression(): {}{ <ADD> unaryExpression() // we allow no-parens functions [ exp x rather than exp(x) ] | unary() unaryExpression() | primaryExpression() } /* predefined unary operators. for any other method, use a <JAVAID> */ void unary(): {}{ <SUB> | "!" | "exp" | "ln" } void primaryExpression(): {}{ number() | identifier() | rate() | rateConstant() | javaID() | "(" expression() ")" } void number(): {}{ <INT> | <NUMBER> } void identifier(): {}{ <ID> } void rate(): {}{ <RATE> ( reactionNumber() | <ID> ) ")" } void rateConstant(): {}{ <RATECONSTANT> reactionNumber() ")" } void reactionNumber(): {}{ ( <ADD> | <SUB> ) [ <INT> ] } void javaID(): {}{ <JAVAID> [ "(" [ argumentList() ] ")" ] } void argumentList (): {}{ expression() ( "," expression() )* } ////////////////// TOKENS ////////////////// Script processing // This is a simplified view of a script: just any sequence of characters from the script marker to // the end of the string. // The real grammar scans the remaining text for specified strings (reserved words like go // or variable names) that need to be modified to work with the mechanism interpreter. // The rest is passed straight through to the BeanShell // interpreter for parsing; that interpreter will decide if any errors exist in the script. void script () : {}{ ( ~[] )* }
